EPEVER IPower Plus 12V 3000W Pure Sine Wave Inverter

The IPower-Plus is a high-frequency pure sine wave inverter featuring digital intelligent control technology.  It ensures reliable operation with lower inrush current, faster response, and robust impact resistance.  Supporting lithium batteries, it’s versatile for DC to AC applications in RVs, boats, homes, and demanding power needs.  Highlights include pure sine wave output, input-output isolation, dual closed-loop control, surge current suppression for lithium batteries, system-friendly wiring, and remote-control options.  International standards approve safety and EMC.

Features
Pure sine wave output
Input to output electrical isolation
Digital dual closed-loop control of voltage and current
Input surge current suppression for lithium battery systems
Output power factor up to 1
Simple system wiring & 180 degrees rotating LCD
Input Protection: Reverse polarity, Low-voltage, Over-voltage Output Protection: Overload, Short circuit, Overheating
Phone and PC remote control through RS485 port
Extra external switch port
Safety (EN/IEC62109) & EMC approved by international standards

Model: IP3000-12-PLUS
Continuous output power: 3000W@35°C @Rated input voltage
Surge power: 6000W@5S
Surge current when power on: <100A
Output voltage: 220VAC; 230VAC
Output frequency: 50/60Hz±0.2%
Output wave: Pure Sine Wave
Rated input voltage: 12VDC
Input voltage range: 10.8~16.0V DC
Rated output efficiency: >87%
Max. output efficiency: >94%(30% loads)
No-load current: <1.6A
USB output: 5VDC/Max.1A
Input terminal: M10
Dimension: 557×231.5×123mm
Net Weight: 10.5kg
